| Ask Lasest Price | |
| Brand Name : | AOK |
| Model Number : | TP |
| Certification : | RoHS, Reach, UL |
| Payment Terms : | T/T |
| Delivery Time : | 13-15working days |
| Attribute | Value | Test Method |
|---|---|---|
| Composition | Ceramic Filler + Silicone | - |
| Color | Pink | Visual |
| Thickness (mm) | 0.5~12.0 | ASTM d374 |
| Density (g/cc) | 2.3 | ASTM D792 |
| Hardness (Shore OO) | 20±5 | ASTM D2240 |
| Tensile Strength(kn/m) | 0.4 | ASTM D624 |
| Elongation % | 52 | ASTM D412 |
| Usage Temperature(℃) | -40~150 | - |
| Electrical | ||
| Breakdown Voltage(kv/mm) | ≥6.5 | ASTM D149 |
| Dielectric Constant(@1mhz) | 5.3 | ASTM D150 |
| Volume Resistivity(Ω.cm) | 1.0*1012 | ASTM D257 |
| Flammability | V-0 | UL94 |
| Thermal | ||
| Thermal conductivity(W/m.K) | 1.2±0.1 | ASTM D5470 |
Advantage
1. The product is environmentally friendly.
2. Be Able to customize production and develop on your own
3. The thermal conductive silicon sheet has the characteristics of
high thermal conductivity, high flexibility and low stress.
4, with the EU CE certification, ISO certification, product testing
report.
5. Short lead time
Product feature:
1.Thermal Conductivity:1.2W/m.K
2.Ultra soft and highly compliant
3.Naturally tacky, easing application
4.Low pressure versus deflection
5.Excellent, high volume applications
