| Brand Name : | AOK |
| Model Number : | TG100 |
| Certification : | RoHS, Reach, UL |
| Payment Terms : | T/T |
| Delivery Time : | 13-15 working days |
White High Temperature Resistance Certificated Heat Sink Thermal Grease For GPU
Attribute | Value | Test Method |
|---|---|---|
Composition | Non-Vulcanized Silicone Oil and Thermally Conductive Filler Mixture | - |
Color | White | Visual |
Density(g/cc) | 2.8 | ASTM D792 |
Usage Temperature(℃) | -40~150 | -- |
Thermal | ||
Thermal conductivity(W/m.K) | 1.0 | ASTM D5470 |
Thermal Resistance(℃-in2/W)0.1mm@50psi) | 0.15 | ASTM D5470 |
Product feature
■ Thermal conductivity: 1.0~5.0 W/m.K
■ No cure required
■ water resistant, non curing, non corrosive to metal materials in
contact (copper, aluminum, steel)
■ Minimizes contact resistance
■ High volume applications
Typical applications
■ Networking and Telecommunications
■ suitable for surface coating and overall potting of microwave
communication, microwave transmission equipment, special power
supply, regulated power supply and other microwave devices
■ Industrial: LEDs, Power Supplies
■ Consumer Electronics: Gaming Systems, LCD TVs, Displays
Product Reminder
Packing specification
Packing specification: 30ml/ 1kg 2kg 10kg
Instructions
Clean the application surface first, then stir the silicone grease
evenly, and then apply the silicone grease to the surface by dot
coating, brushing or screen printing. If screen printing is used,
it is recommended to use 60-80 mesh nylon screen, and a rubber
scraper with a hardness of about 70. When coating, apply silicone
grease at about 45 degrees to the coated surface. After the
operation, unused products should be sealed and stored in time.
Shelf life & Storage:
Shelf life of the product is 6 months after date of shipment. Store in a cool, dry, well ventilated place.
|
|
